LabStationS
FullQuant’s LabStations are purpose designed for computer controlled lab instrumentation such as AA, ICP-OES, ICP-MS, GC, LC, GC/MS and LC/MS. Built to high specifications, our LabStations provide a solid, safe working platform for your analytical instrument and sample introduction/sampling device such as autosampler, GC, LC or CE.
Built-in PC, keyboard and monitor mounts reduce lab clutter and keep your computing equipment away from chemical spills. A PC holder mounts the PC under the work surface, and the keyboard and mouse sit on an articulated tray that swings under the work surface when not in use. The monitor is mounted on a fully articulated steel arm, adjustable for height and reach. LabStations are fitted with 4” total lock wheels, allowing you to configure your instrumentation and lab layout however you want.
LabStations are available in 4 different width sizes to suit different instrumentation (measurements shown below are depth x width x height). The model number denotes the work surface width in inches. Choose the width to suit your needs, depending on the size of your analytical instrument, and what autosampler/sample introduction device needs to fit on the LabStation. The LabStation 36 is ideal for a GC or LC, which can be rolled up next to an ICP-MS for GC-ICP-MS or LC-ICP-MS work. It also includes a 12” tall drawer, and a full depth foot shelf. The LabStation 84 is also available with a cabinet on the right side to house a rotary pump. The cabinet is fitted with twin doors and is lined with sound deadening foam. A rear opening allows for cable and vacuum line connections and also for heat removal.
To download a spec sheet with technical drawing of each model, click on the link on the right side of the table.
LabStation Models with Typical Application
LabStation Model |
Dimensions |
Weight |
Typical Use |
Spec Sheet/ |
LabStation 36 |
D30” x W36” x H35" |
approx. 80lbs |
GC – e.g. Agilent 7890 |
 |
LabStation 60 |
D30” x W60” x H35" |
approx. 141lbs |
Small ICP-MS with autosampler – e.g. Agilent 7700 with Cetac ASX 520 |
|
LabStation 72 |
D30” x W72” x H35" |
approx. 159lbs |
Mid size ICP-MS with autosampler – e.g. Agilent 7500 with Cetac ASX 520 |
|
LabStation 84 |
D30” x W84” x H35" |
approx. 180lbs |
Larger ICP-OES with autosampler – e.g. Agilent 700 Series with SPS3. |
|
LabStation 84 |
D30” x W84” x H35" |
approx. 210lbs |
For ICP-MS, GC/MS or LC/MS where reduced rotary pump noise is required. |
|
